Description
Composition: low molecular weight polymer of methyl-(3,3,3-trifluoropropyl)siloxane (100% fluorosilicone polymer)
Synonyms: Trifluoropropylmethylsiloxane, Methyl Trifluoropropyl Silicone Fluid, Trifluoropropyl methyl siloxane polymer
CAS No: 63148-56-1
Equivalent Product: Dow Corning FS 1265 or Dowsil FS 1265
Chemical Structure:
Fluorosilicone oil TPD-FS8012 is methyl terminated low molecular weight polymer. Since the introduction of trifluoropropyl on silicon atoms, it has excellent oil & solvent resistance, good lubricity, low surface tension and low refractive index, while remains wide working temperature range of silicone oil(-40~204℃).
Features
- EU REACH Registration
- Excellent oil & solvent and chemical resistance
- Excellent oxidation resistance
- Low surface tension and low refractive index
- Good compatibility with most elastomers
- Wide range of working temperature(-40~204℃)
Technical Index
| Item | Unit | TPD-FS8012-300 | TPD-FS8012-500 | TPD-FS8012-1000 | TPD-FS8012-10000 |
|---|---|---|---|---|---|
| Appearance | Colorless transparent or light yellow transparent liquid | ||||
| Viscosity at 25℃ | mm2/s | 300 | 500 | 1,000 | 10,000 |
| Viscosity at -18℃ | mm2/s | 5,200 | 12,000 | 20,000 | 420,000 |
| Viscosity at 100℃ | mm2/s | 27 | 36 | 69 | 670 |
| Viscosity at 204℃ | mm2/s | 5.3 | 6.4 | 10.3 | 75 |
| Flashing Point | ℃ | ≥260 | ≥270 | ≥300 | ≥310 |
| Freezing Point | ℃ | ≤-47 | ≤-40 | ≤-31 | ≤-31 |
| Working Temperature | ℃ | -40~204 | |||
| Volatility (200℃/4hr) | % | ＜5 | |||
* Fluorosilicone oil TPD-FS8012 is also available in 100mm2/s.
- IR Chart
Applications
Used as a base oil for grease & paste with requirement of corrosion and solvent resistance.
Solvent antifoaming in the chemical and petroleum industries.
Used in vacuum pump as a lubricating oil to handle with highly reactive gas.
Packing
5KG, 25KG, 50KG or 200KG Plastic or Iron drums.
Transportation & Storage
1. Transported as non-dangerous chemicals.
2. Require sealed and airproof packing.
3. Should be stored in a shady cool, ventilated warehouse.
4. Keep away from fire, heat source, direct sunlight and rain.
5. Avoid from oxidant, acid, alkali chemical materials and other impurities.
Shelf Life
Shelf Life: 2 years.
